Mainboard Asus PRIME H610M-E D4
-
Chipset: Intel H610
-
Socket: Intel LGA 1700
-
Kích thước: M-ATX
-
Số khe RAM: 2
36 tháng
Tại sao bạn chọn Tứ Gia
- Giao hàng miễn phí lên tới 150km
- Thanh toán thuận tiện
- Sản phẩm 100% chính hãng
- Bảo hành tại nơi sử dụng
- Giá cạnh tranh nhất thị trường
- Đổi mới 30 ngày đầu nếu có lỗi của nhà sản xuất
Thông số kỹ thuật
Sản phẩm |
Bo mạch chủ |
Tên Hãng |
Asus |
Model |
H610M-E D4 |
CPU hỗ trợ |
Intel |
Chipset |
H610 |
RAM hỗ trợ |
2 x DIMM, Max. 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory |
Khe cắm mở rộng |
Intel® 12th Gen Processors 1 x PCIe 4.0 x16 slot Intel® H610 Chipset 1 x PCIe 3.0 x1 slot
|
Ổ cứng hỗ trợ |
Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports Intel® H610 Chipset M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x2 mode) 4 x SATA 6Gb/s ports |
Cổng kết nối (Internal) |
Fan and Cooling related 1 x 4-pin CPU Fan header 2 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 2 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 1 x RGB header 1 x Clear CMOS header 1 x Front Panel Audio header (AAFP) 1 x COM Port header 1 x S/PDIF Out header 1 x Speaker header 1 x SPI TPM header (14-1pin) 1 x 10-1 pin System Panel header |
Cổng kết nối (Back Panel) |
2 x USB 3.2 Gen 1 ports (2 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x DisplayPort 1 x D-Sub port 1 x HDMI® port 1 x Realtek 1Gb Ethernet port 3 x Audio jacks 1 x PS/2 Keyboard (purple) port 1 x PS/2 Mouse (green) port |
LAN / Wireless |
|
Kích cỡ |
mATX Form Factor 9.6 inch x 8.3 inch ( 24.4 cm x 21.1 cm ) |
Chi tiết sản phẩm
Asus PRIME H610M-D là dòng bo mạch chủ chipset H610 phổ thông, phù hợp với các vi xử lý Pentium, Celeron,i3 & i5 non K thế hệ Alder Lake.
Tính năng nổi bật
- Khe M.2 PCI-e Gen 3 cho SSD M.2 tốc độ cao
- Khe PCI-E gen 4
Tính năng
Hiệu năng
Bo mạch chủ này dành cho ai?
Mainboard Asus PRIME H610M-E D4 phù hợp với các bộ máy tính phổ thông và tầm trung, cho nhu cầu chơi game và làm việc văn phòng cũng như Multimedia cơ bản.
